ixel pitch |
5mm |
|
Pixel Density |
40,000 dots/m² |
|
Pixel configuration |
1R1G1B |
|
LED type |
3-in-1 SMD2727 |
|
Module size |
320*160mm |
|
Module weight |
450g |
|
Module resolution |
64*32dots |
|
Module quantity |
19.53 pcs/m² |
|
Min. Viewing Distance |
≥5m |
|
Brightness |
≥5500 cd/m² |
|
Viewing Angle |
H≤120° V≤120° |
|
Driving Mode |
1/8 scan constant current driving |
|
Interface |
HUB75 |
|
Input voltage |
4.8-5.5VDC |
|
Max. Power Consumption |
623 w/m² |
|
Avg. Power Consumption |
311 w/m² |
|
Max. Current |
7.6A |
|
Frame rate |
60 frames/s |
|
Refresh Rate |
≥1920Hz |
|
Defective Dots Rate |
<0.0001 (LED display line standard: ≤ 0.0003) |
|
Decay Rate |
≤5%/year |
|
Brightness Conformity |
>95% |
|
MTBF |
≥10000 hours |
|
Lifespan |
≥100000 hours |
|
Protective function |
Over-heat/Over-load /Power-down /Power-leakage/Lightning-protection etc. |
|
Operating Temperature |
-10℃~+40℃ |
|
Operating Humidity |
10-80% no condensation |
|
Storage Temperature |
-20℃~+60℃ |
|
Storage Humidity |
10-85% no condensation |
