Model Number |
N200V5 |
|
Brand |
G-Energy |
|
Size |
195×110×30mm |
|
Wiring Instructions |
Input (L N FG), output (V- V- V- V + V + V +) |
|
AC Input Voltage Range |
200~250V/AC |
|
Input Rated Voltage |
220V/AC |
|
Input Voltage Frequency |
47~63Hz |
|
Average Input Current |
<2.5A |
|
Overall Efficiency |
≥78% |
|
Output Voltage |
5V |
|
Adjustable Output Voltage Range |
4.6~5.4V |
|
Output Rated Current |
0~40A |
|
Output Ripple and Noise (Vp-p) |
150mV |
|
Boot Time |
100ms |
|
Output Overvoltage Protection |
Have |
|
Output Overcurrent Protection |
45~65A |
|
Output Short Circuit Protection |
≥45A |
|
Working Temperature |
-20~50℃ |
|
Storage Temperature |
-30~80℃ |
|
Cooling Method |
Air Cooled |
|
MTBF |
≥40000 hours |
|
Weight |
0.55kg |
|
Certificate |
CE,ROHS,FCC,ISO9001,TUV |
|
Package |
|
|
Package (pcs/carton) |
10pcs |
|
Packing Size |
385*275*145 |
|
G.W(Kg/carton) |
5.824kg |
