P2 160 X 320

Nhà cung cấp: Công ty TNHH Led Hoa Phượng Việt Nam
Mã sản phẩm: (Đang cập nhật...)
Tình trạng: Còn hàng
Liên hệ
Pixel pitch 2mm Pixel Density 250000 dots/m² Pixel configuration 1R1G1B LED type 3-in-1 SMD1515 ...

Pixel pitch

2mm

Pixel Density

250000 dots/m²

Pixel configuration

1R1G1B

LED type

3-in-1 SMD1515

Module size

320*160mm

Module weight

425g

Module resolution

160*80dots

Module quantity

19.53 pcs/m²

Min. Viewing Distance

≥2m

Brightness

≥600 cd/m²

Viewing Angle

H≤140°  V≤140°

Driving Mode

1/40 scan constant current driving

Interface

HUB75

Input voltage

4.2-5VDC

Max. Power Consumption

410W

Avg. Power Consumption

205W

Max. Current

4.2A±0.5A

Frame rate

60 frames/s

Refresh Rate

1920Hz

Defective Dots Rate

<0.0001 (LED display line standard: ≤ 0.0003)

Decay Rate

≤5%/year

Brightness Conformity

>95%

MTBF

≥10000 hours

Lifespan

≥50000 hours

Protective function

Over-heat/Over-load /Power-down /Power-leakage/Lightning

-protection etc.

Operating Temperature

-10℃~+40℃

Operating Humidity

10-80% no condensation

Storage Temperature

-20℃~+60℃

Storage Humidity

10-85% no condensation

Control System Parameter

Color temperature

Adjustable by software

Brightness control

256 levels, automatic adjustment.

Control way

Computer, real-time, off-line, wireless, network etc.

Communication Distance

Cat5 UTP 100 meters, max. 130 meters; or optical fiber.
